EA-PS9000ZH/EA-PSI9000ZH/ea-ps80002U/ea-psI80002U/FET-开关
包括实验室电源用两象限模组/INCL.2-QUADraNTSMODULEFORLABPOWERSUPPLIES

FET-开关/FETSwitchEA-PS9080-100ZHKFZ

•高达2400W峰脉冲功率的内部负载模组•Internalloadmoduleupto2400Wpeakpulsepower
•峰脉冲电流高达200A•Peakpulsecurrentupto200A
•连续输出功率为150W•Continuouspower150W
•模拟汽车引擎启动电性测试•Simulationofenginestartforcarelectronictests
•为汽车高保真度HIFI测试提供大电流•HighcurrentforcarHIFItests
•输出电压高达80V，也适用42V汽车网•Voltageupto80V,alsoforthe42Vautomotivenet
•符合DIN40839标准电压序列•IntegratedvoltagesequenceaccordingDIN40839
•无外部负载时快速电压阶跃•Fastvoltagestepwithoutexternalload

概要General
本系列有EA-PS9000ZH,EA-PSI9000ZH,EA-PS8000FortheseriesEA-PS9000ZH,EA-PSI9000ZH,EA-PS
U和EA-PSI8000U型内部电子负载产品。8000UundEA-PSI8000Uaninternalelectronicload
利用本负载电，可速又精地降低电压，从而得所isavailable.
需高输出电量。通过相同方式给连接设备电，借此到Thenecessaryhighoutputcapacitycanbeachievedwith
速动态控制设备的目的。ZH类型用源-汇原理作。avoltagereductionquicklyandaccuratelybyadischarge
指产品可根据需求电压/电流源和电流沉的方式作。withthisload.Inthesamewaythecapacityofconnected
速的曲线描迹和特短减少时间，使产品应用於复杂和equipmentisdischarged,wherebyarapidcontroldyna-
昂贵线性控制器支援的设备上。结合有源负载模组能行micoftheunitsisachieved.TheZH-modelsoperatewith
脉动作，可允许高400W的峰­值功率，有内置热过thesource-sinkprinciple.Thismeansthattheunitscan
保护功能。function,accordingtorequirements,asvoltageandcur-
rentsourcesandaascurrentsinks.Rapidcurvetracing
andespeciallyshortreductiontimesenabletheirusein
applicationswhichpreviouslycouldonlybesupportedby
complexandexpensivelinearcontrollers.Theintegrated
activeloadmoduleissuitableforpulsedoperationandcan
takeapeakpowerofupto2400W,withaninbuiltthermal
overloadprotection.

马达起动机序列Motorstartsequence
通过推动按钮，部触发信或函管理Bypush-button,anexternaltriggersi-
器的激活，可重现符合DIN40839标准的gnaloractivationofthefunctionmanager
汽车功率用电压曲线。(EA-PSI9000only),thevoltagetraceof
起动电压完全可调，适合各标准电压，anautomotivepowernetworkaccording
如：V，4V和未来的未来的4V。toDIN40839canbereproduced
Thestartingvoltageisfullyadjustable
andisthereforesuitableforallstandard
voltages,e.g12v,24vandthefuture
4v.
符合DIN40839标准的电压曲线图
VoltagecharacteristicDIN40839
